Construction Surveying

Axis3D COS - Construction Surveying

Construction surveying for tunneling and civil engineering projects

Construction Surveying

Various calculation options: Perfect solutions even for unusual tasks.

Precise results: Proven calculation routines for reliable results.

Flexible data structure: Data structure designed individually by the user according to project requirements.

Efficient workflow: Intuitive user interface guides users and makes work considerably easier.

Coordinate Calculation

Data Management

Stakeout and Control

Coordinate CalculationAxis3D COS greatly simplifies the professional analysis of measurement data. Accurate trigonometric results are guaranteed by reliable adjustment routines that take refraction into account. Easy evaluation of leveling data minimizes analysis effort and the intuitive user interface guides users through the program.
Data ManagementUsers can manage large volumes of data individually and by project. Coordinates of reference points, profile-related points, and other project points are stored securely, as are shutter definitions and cross-sections for profile checks. The clear data structure provides a quick overview of the entire project.
Stakeout and ControlVarious calculation routines are available for stakeout and control tasks, such as plumbing points onto center lines, 3D lines, and 3D planes; point calculation along center lines and 3D lines; construction laser calculations; coordinate comparison. NATM-profile and TBM guidance checks can be evaluated easily and displayed in clear graphics.

Functionality

Applications

General
  • Easy to use, flexible user interface design
  • 3D display of the project situation with tunnel geometry, survey points, and sightings
Coordinate Calculations
  • Based on data obtained from polar measurements or sets of angles
  • Supports Leica GSI8 and GSI16 data formats (other manufacturers on request)
  • Includes leveling data
  • Free Station (3D) with survey point calculation
  • Calculation of linked stations with optimized adjustment algorithms
  • Automatic recognition of reference point IDs, even without measured distances
  • Calculation of leveling runs
Setting Out
  • To center lines
  • To nominal profiles
  • To 2D and 3D lines and planes
Point Calculation along defined lines and curves
  • To center line
  • To nominal profile
  • To 2D and 3D lines
  • Of borehole axes for umbrella fore-poling
Tunneling Laser
  • Manage construction laser definitions
  • Laser stakeout and control

Control
  • Profile checks with graphical output
  • TBM guidance checks with graphical output
  • Coordinate comparison for absolute and centerline related coordinates
  • Shutter profile check
Other Calculations
  • First and second geodetic problems
  • Helmert transformation
    (1D, 2D, 3D)
  • Intersection of 2D and 3D center lines
Alignement
  • Calculation of clothoid (Euler’s spiral) elements
  • Curve sequence clothoid - clothoid
  • Curve sequence clothoid - circle - clothoid
  • Curve sequence outer clothoid
  • Curve sequence transition curve
Geometry Manager (Axis3D GeoMan)
  • Analytical definition of tunnel geometry according to design
  • Plausibility checks and 3D visualizations
  • Highly accurate transformation between absolute coordinates and axis-related coordinates
Database
  • Management of points, cross-sections for profile and TBM guidance control, shutter definitions, etc.
  • Individual, project related data structure
  • Interfaces for data import/export
  • SQLite, Oracle, Microsoft SQL-Server, Interbase

tunnelingTunneling
Tunnels, caverns, cut and cover construction, above ground structures

Open CutsShafts, Open Cuts
Secured slopes; sheet pile-, secant pile-, and diaphragm- walls

Civil Engineering StructuresCivil Engineering Structures
Bridges, retaining walls, building pits

System Information

Hardware
(not included)
  • PC with at least 2 USB ports
  • 21" screen recommended
Software
  • Axis3D PC software, incl. USB or SD dongle
  • Languages: German, English; French (coming soon)
  • Operating systems:
    Windows Vista, Windows 7, Windows 8, Windows 10 (32-bit and 64-bit, respectively)
